Weight
1600
kg
Engine power
STAGE V
15.9
kW
Digging depth
2145
mm
Type
Zero tail swing
Extendible tracks
Product details
FIND OUT
THE TECHNICAL DETAILS AND
FEATURES
THE TECHNICAL DETAILS AND
FEATURES
Information
Do you want more information? Fill in the following form and we you will be immediately contacted.
General Features
- Innovative design with the tail always remaining within the width of the tracks (Zero Tail Swing).
- Variable track width (retracted crawler width of 990 mm) provides easy access to very small job sites.
- STAGE V diesel engine.
- Piston pumps and double speed gear motors.
- Extraordinary manoeuvrability due to the use of pilot assisted controls (joy-sticks) to operate arms and buckets.
- Proportional rollers on the joy-sticks to control the boom swuing and the simple/double effect P.T.O. (no pedals).
- Travel levers and servo-controls disabling system by armrest lifting prevents accidents due to unexpected machine movement during entry or exit.
- Suspension and adjustable operator’s seat increases productivity by providing optimum comfort. Also tilting to allow easy maintenance of the main components.
Standard equipment
- Canopy according to TOPS-FOPS norms with removable roof
- 2-speeds travel electric switch
- Completely servo controlled commands
- Oil recovering system on dipstick arm
- 1000 mm long dipstick
- Variable track width retractable to mm 990
- Hydraulic Power Take-Off (P.T.O.)
- USE & MAINTENANCE and SPARE PARTS MANUAL
Options
- Buckets of mm 250, 300, 350, 450, 500 standard, for rocks and for Quick Hitches
- Buckets for slopes standard or swivelling
- Buckets for clening
- Mechanical or hydraulic Quick Hitches
- Hydraulic breaker
- Hand breaker
- Hydraulic drill/rig
- Various auxiliary hydraulic lines
Data, features and illustrations are not binding and may be altered without any notice.
