TC95d 2018-06-14T16:41:18+00:00

Max payload

950

Kg

Engine power

9.6

KW

Width

800

mm

Supply

diesel

Product data sheet

FIND OUT
THE TECHNICAL DETAILS AND
FEATURES

Download the brochure

Information

Do you want more information? Fill in the following form and we you will be immediately contacted.

Name*
Surname*
Email*
Phone*
Request

Type of request*

InformationsAfter-sales services
* Fields with asterisk are required

Standard equipment

Our New tank/skip New design Reinforced Rubber Diesel Hydrostatic Hydraulic new minidumper CH-2N is the technological development of the previous model CH-2R, of which has been maintained the best characteristics, even improved with a series of new technical solutions together with a more up-to-date design;

  • with round shaped design, recalling the line of all current models.
  • of the engine cover protecting also the battery (which is now “High capacity” with fast discharge rate of 420 A to make the start of the engine easier even in arctic zones).
  •  idler with new watertight bearings and with a loading capacity increased of 70% than the previous version.
  •  The engine has been relocated in order to reduce the rear size so to give an higher stability to the empty machine.
  • Larger radiator and heat exchanger.
  •  track built with a monobloc structure incorporating a core of continuous steel wire and heat treated embedded metals.
  • or petrol engine 13 Hp, water cooled, with electric start as standard equipment.
  •  transmission consisting in two axial pistons pumps of variable displacement and two orbital motors of fixed displacement, with planetary drives with multiple disk brakes and negative control system.
  • P.T.O. (optional) with flow of 20 l/min and pressure of 140 bar.
