TC85 2018-09-11T10:01:26+00:00

Max payload

850

Kg

Engine power

9.6

KW

Width

800

mm

Supply

petrol

Product data sheet

FIND OUT
THE TECHNICAL DETAILS AND
FEATURES

Download the brochure

Information

Do you want more information? Fill in the following form and we you will be immediately contacted.

Name*
Surname*
Email*
Phone*
Request

Type of request*

InformationsAfter-sales services
* Fields with asterisk are required

Standard equipment

• Tracked undercarriage with hydrostatic transmission fitted with a modular chassis able to receive a wide number of equipments.
• Double effect cylinder for the frontal lifting of the accessories.
• Rubber tracks realized in monobloc structure with core in iron wire and inserts in treated iron.
• Endothermic petrol engine, air cooled; manual start by rope tearing.
• Hydrostatic transmission controlled by manual levers with 3 gear pumps and fixed displacement orbital engines. Steering throughout the rotation of the tracks.
• Two levers connected with the hydraulic distributor to control travelling. Each lever controls independently the movements of each track, enabling the operator to have a complete control in every phase.
• 2nd travel speed is operated by a lever on the hydraulic distributor
• Loading skip with large angle of discharge. The round shaped design gives both to the machine a new styling and allows a quick discharge of the transported materials.
• Operator’s footboard.

Optional equipment

• Electric start
• Engine cover
• The double effect P.T.O. with a delivery of max. 20 lt/min and pressure P=150 bar, can be used for auxiliary equipments
• The selfloading shovel allows an optimal charging of the skip. The small lateral dimension of the machine is also due to the position of the shovel lifting cylinders
Data, features and illustration are not binding and may be altered without any notice.
